Description
40GP32AF
40GP32AF is a Siemens Class 40 motor control contactor designed for 3-phase applications with a 60 amp rating and 600 volt capacity.40GP32AF features a Size 2.5 frame, 3 poles, and operates with a 110V 50Hz / 120V 60Hz coil voltage. It is a non-reversing contactor suitable for full voltage motor starting and control.
- Amperage: 60A
- Voltage: 600V AC
- Poles: 3
- Frame/Size: 2.5 (Class 40)
- Coil Voltage: 110V 50Hz / 120V 60Hz
- Contact Configuration: 3-phase full voltage
- Mounting Type: Open
- Interrupt Rating: Standard for Class 40 contactors
- Operating Temperature: -20 to 40°C
- Non-reversing design
- Typical Duty Cycle: 10,000,000 cycles
- Certifications: UL Listed, CSA Certified (typical for Siemens contactors)
Specifications
- Part Number: 40GP32AF
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Class 40
- Type : 40GP
- Voltage : 600
- Amperage : 60
- Phase : 3
- Poles : 3
- Horse Power : HP @ 3 Phase - 208V 15 hp HP @ 3 Phase - 240V 20 hp HP @ 3 Phase - 480V 30 hp
- Aux Contacts : 1NO
- Coil Voltage Maximum : 120
- Full Load Amps : 60 A
Product Data
- UPC : 783087068421
- GTIN : 00783087068421
- Country of Origin : Mexico
- Dimensions : 0.929 x 0.929 x 0.776 inch
- Weight : 3.999
- Certification : REACH Art 33
