40GP32AA - Siemens 60A 600V 3-Pole Motor Contactor Size 2.5 with 110-240VAC Coil

40GP32AA

40GP32AA is a Siemens motor contactor designed for reliable motor control applications with a 60 amp rating and 600 volt maximum operating voltage.This non-reversing contactor features a size 2 1/2 frame, three poles, and supports three-phase full voltage operation. It has a coil voltage range of 110-120/220-240 VAC at 60 Hz and includes one normally open auxiliary contact. The contactor is suitable for motor loads up to 15 hp at 230 V, 20 hp at 460 V, and 30 hp at 575/600 V. It offers a mechanical service life of approximately 10 million operating cycles and is built for durability and efficient motor control.

Key Specifications
• Amperage: 60 A
• Voltage: 600 V max operational
• Poles: 3
• Mounting Type: Size 2 1/2 frame
• Coil Voltage: 110-120/220-240 VAC, 60 Hz
• Contact Configuration: 3 main NO contacts, 1 NO auxiliary contact
• Horsepower Ratings: 15 hp @ 230 V, 20 hp @ 460 V, 30 hp @ 575/600 V
• Mechanical Service Life: 10,000,000 cycles typical
• Non-reversing contactor
• Control Supply Power: 218 VA pickup, 25 VA holding
• UL Contact Rating: 10A @ 600 VAC (A600), 2.5A @ 300 VDC (Q300)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: 40GP32AA
• Manufacturer : Siemens
• Brand : Siemens
• Category : Motor Control
• Item Subcategory : Contactor
• Family : Class 40
• Type : 40GP
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 15 hp HP @ 3 Phase - 240V 20 hp HP @ 3 Phase - 480V 30 hp
• Aux Contacts : 1NO
• Coil Voltage Maximum : 240
• Full Load Amps : 60 A



Product Data

• UPC : 783087068377
• GTIN : 00783087068377
• Country of Origin : Mexico
• Dimensions : 0.929 x 0.929 x 0.776 inch
• Weight : 3.999
• Certification : REACH Art 33
