3VA6110-5HN31-0AA0 - Siemens 3VA6 Molded Case Circuit Breaker, 3-Pole, 100 A, 600 V AC, Thermal-Magnetic Trip

3VA6110-5HN31-0AA0

3VA6110-5HN31-0AA0 is a Siemens 3VA6 molded case circuit breaker rated for 100 A continuous current at 600 V AC with 3-pole configuration and electronic trip protection. This UL Frame 150 breaker features Class M breaking capacity of 35 kA at 480 V and is designed for line protection with LSI (Long Short-circuit Inverse) and ETU350 overcurrent release. The compact design integrates modular accessories, retrofittable communication capability, and plug-in or draw-out technology for flexible installation and maintenance.

• Amperage Rating: 100 A
• Voltage Rating: 600 V AC
• Frequency: 50/60 Hz
• Number of Poles: 3
• Series: 3VA6
• Frame: UL Frame 150
• Trip Unit: Electronic (ETU350)
• Interrupt Rating: 35 kA at 480 V
• Enclosure Type: IP40
• Operating Temperature: -25 to 70 deg C
• Dimensions: 7.8 in H x 4.13 in W x 4.21 in D
• Connection Type: Feed-Thru

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3VA6110-5HN31-0AA0
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : 3VA
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LSI - Long Time, Short Time and Instantaneous
• Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
• Protection : Solid State

Product Data

• UPC : 804766307072
• GTIN : 804766307072
• Weight : 8
• Standards : UL Listed
• Certification : UL Listed
