2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
3VA5330-6EC31-0AA0
3VA5330-6EC31-0AA0 is a Siemens Sentron 3VA5 series molded case circuit breaker with thermal magnetic trip unit.This 3-pole circuit breaker features TM230 trip unit with fixed thermal overload protection at 300A and adjustable magnetic short-circuit protection. It offers high breaking capacity class H, rated for 690V AC/500V DC operation in industrial and commercial applications. Line protection design without lugs, IP40 enclosure.Key Specifications
- Amperage: 300A
- Poles: 3
- Frame: 3VA53 (400A frame)
- Trip Unit: TM230, thermal magnetic (FTAM)
- Interrupt Rating: 65kA@480V, 25kA@600V, 100kA@240V
- Voltage Rating: 690V AC, 500V DC
- Frequency: 50/60 Hz
- Breaking Capacity Class: H
- Approvals: UL
- Enclosure: IP40
Specifications
- Part Number: 3VA5330-6EC31-0AA0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : 3VA
- Amperage : 400
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Functions : FTAM
- Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
- Protection : TM230
Product Data
- UPC : 80476679321
- GTIN : 00804766793219
- Weight : 18
- Standards : UL Listed
- Certification : UL Listed
