3VA5225-6EC61-0AA0 - Siemens 250A 600V 2-Pole Thermal Magnetic Circuit Breaker 3VA52 Frame 65kA Interrupt Rating

3VA5225-6EC61-0AA0

3VA5225-6EC61-0AA0 is a Siemens 3VA5 series molded case circuit breaker rated for 250A at 690VAC/500VDC with a 64kA interrupt rating and thermal-magnetic trip unit. This 2-pole breaker is designed for line protection applications and features fixed DIN rail mounting with IP40 enclosure rating. The breaker operates across 50/60Hz frequencies and is suitable for industrial power distribution systems requiring reliable overcurrent and short-circuit protection. Operating temperature range spans -25 to 70 degrees Celsius with a mechanical service life of 15,000 switching cycles. Power loss is 38.67W total or 19.33W per pole at rated current in hot operating state. The unit weighs 1.84kg and measures 7.28 inches in height, 4.13 inches in width, and 4.21 inches in depth.

• Amperage Rating: 250A
• Voltage Rating: 690VAC / 500VDC
• Interrupt Rating: 64kA
• Number of Poles: 2
• Series: 3VA5
• Trip Type: Thermal Magnetic
• Frequency: 50/60Hz
• Mounting: Fixed DIN Rail
• IP Rating: IP40
• Operating Temperature: -25 to 70 degrees Celsius
• Mechanical Service Life: 15,000 cycles
• Power Loss: 38.67W total

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3VA5225-6EC61-0AA0
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : 3VA
• Voltage : 600
• Amperage : 250
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 80476630817
• GTIN : 00804766308178
• Weight : 2
• Standards : UL Listed
• Certification : UL Listed
