3VA5220-6EC61-0AA0 - Siemens 200A 600V 2-Pole Molded Case Circuit Breaker, 3VA52 Frame, 65kAIC, Feed-Thru, Thermal Magnetic Trip, UL Listed

3VA5220-6EC61-0AA0

3VA5220-6EC61-0AA0 is a Siemens 3VA5 molded case circuit breaker with 200A rating, 2 poles, and 65 kA interrupting capacity at 480V.This UL-listed circuit breaker from the 3VA5 series features Frame 250, line protection with TM230 trip unit (FTAM), fixed overload protection Ir=200A, and adjustable short-circuit protection Ii=5...10 x In. It supports operational currents up to 200A at 40C, with rated insulation voltage of 800V, AC operating voltage up to 690V, and DC up to 500V. Breaking capacity class H per IEC 60947 includes Icu 100 kA at 240V, 70 kA at 415V, and 10 kA at 690V.

• Part Number: 3VA5220-6EC61-0AA0
• Manufacturer: Siemens
• Series/Frame: 3VA5 UL Frame 250
• Amperage: 200A (at 40C)
• Poles: 2
• Interrupt Rating: 65 kA at 480V (UL)
• Voltage: 690V AC / 500V DC
• Insulation Voltage: 800V
• Trip Unit: TM230 (FTAM), Ir=200A fixed, Ii=5...10 x In
• Breaking Capacity Class: H
• Mounting: DIN Rail compatible
• Power Loss: 28W maximum

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3VA5220-6EC61-0AA0
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : 3VA
• Voltage : 600
• Amperage : 200
• Phase : 1
• Poles : 2
• AIC rating : 65kA@480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 80476630833
• GTIN : 00804766308338
• Weight : 4
• Standards : UL Listed
• Certification : UL Listed
