Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
3VA5211-5EC31-0AA0
3VA5211-5EC31-0AA0 is a Siemens molded case circuit breaker designed for reliable protection in electrical distribution systems.This circuit breaker features a 3VA5 UL frame with a thermal-magnetic trip unit, providing 110 amps of current rating and 3 poles. It supports voltage ratings up to 690 VAC and 750 VDC, with a medium (Class M) breaking capacity of 35 kA at 480 V. The breaker is suitable for DIN rail mounting and operates at 50/60 Hz frequency.
- Manufacturer: Siemens
- Part Number: 3VA5211-5EC31-0AA0
- Current Rating: 110 A
- Voltage Rating: 690 VAC / 750 VDC
- Poles: 3
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 35 kA @ 480 V (Class M)
- Frame/Series: 3VA5 UL Frame 250
- Mounting Type: DIN Rail
- Frequency: 50/60 Hz
- Certifications: UL Listed
Specifications
- Part Number: 3VA5211-5EC31-0AA0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : 3VA
- Voltage : 600
- Amperage : 110
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 80476630868
- GTIN : 00804766308680
- Weight : 2
- Standards : UL Listed
- Certification : UL Listed
