Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
3VA4180-4ED24-0AA0
3VA4180-4ED24-0AA0 is a Siemens molded case circuit breaker designed for reliable low-voltage system protection.
This 2-pole breaker features an 80A thermal-magnetic trip unit (TM210), offers a 25kA interrupting capacity at 480V, and is built on the robust 3VA4 frame. It is suitable for line protection applications and is UL listed for safety and compliance.
-
Key Specifications
- Amperage: 80A
- Voltage: 480V AC
- Poles: 2
- Mounting Type: Fixed (clamp connection)
- Interrupt Rating: 25kA at 480V
- Series/Frame: 3VA4, UL Frame 125
- Trip Unit: TM210 (thermal-magnetic, fixed)
- Certifications: UL Listed (SEAB), HACR Type
- Breaking Capacity: Class S
- Overload Protection: Ir = 80A (fixed)
- Short-Circuit Protection: Ii = 10 x In
- Power Loss: 11W max
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 3VA4180-4ED24-0AA0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : 3VA
- Voltage : 480V AC
- Amperage : 80
- Phase : 1
- Poles : 2
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : LI
- Terminal Connection : Load Side Lug
- Frame Size : 125
- Temp Rating : -13¡F-158¡F (-25¡C-70¡C)
- Protection : Thermal Magnetic
- Trip Type : TM210
Product Data
- UPC : 804766943201
- GTIN : 00804766943201
- Country of Origin : Mexico
- Dimensions : 6.614 x 5.315 x 2.283 inch
- Weight : 1.133
- Standards : UL Listed
- Certification : UL Listed
