3UB81234DW2 - Siemens 5.5-22A 3-Phase Solid State Overload Relay ESP200 Series DIN Rail Mount

3UB81234DW2

3UB81234DW2 is a Siemens solid state overload relay designed for motor protection with a 5.5 to 22 ampere rating and 3-phase operation.This ESP200 series relay features a 1NO-1NC auxiliary contact configuration, supports direct or stand-alone mounting on DIN rails, and includes screw terminal connections. It operates within a temperature range of -25 to 65 degrees Celsius and offers Class 5...30 trip characteristics for reliable motor overload protection.

• Amperage rating: 5.5 to 22 A
• Voltage rating: up to 600 VAC
• 3-phase solid state design
• Contact form: 1NC-1NO auxiliary contacts
• Mounting type: DIN rail or direct/stand-alone
• Terminal type: screw terminals
• Series: ESP200, Size A1
• Trip class: 5...30
• Operating temperature: -25 to 65 °C
• UL and CSA approved
• Manual or automatic reset

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3UB81234DW2
• Manufacturer : Siemens
• Brand : Siemens
• Category : Motor Control
• Item Subcategory : Overload Relay
• Family : ESP200
• Type : 3UB8
• Relay Style : Solid State
• Amperage Maximum : 22
• Amperage Minimum : 5.5

Product Data

• UPC : 662643897210
• GTIN : 00662643897210
• Country of Origin : Mexico
• Dimensions : 3.15" x 2.60"
• Weight : 0.529
• Certification : REACH Art 33 Duty to Inform According to the Current List of Candidates Lead CAS-No. 7439-92-1 Greater Than 0, 1 % (w/w), RoHS 07/01/2006
