3TA100FB - Cutler Hammer 100A 3-Pole Lug Terminal Kit for Series C FB Frame Breakers

3TA100FB

3TA100FB is a line and load terminal lug kit designed for Eaton Cutler Hammer molded case circuit breakers. This aluminum terminal kit provides reliable connections for F-frame breakers with a 100 amp current rating and 600VAC voltage rating. 3TA100FB features Type KD short stud construction and accommodates wire gauges from 14 AWG to 1/0 AWG (2.5-50 mm squared metric). The kit includes 3 lugs with 1 barrel per lug and is manufactured from steel with copper/aluminum wire compatibility. Suitable for use with Type RC molded case circuit breakers in 3-pole configurations.

• Current Rating: 100 Amps
• Voltage Rating: 600VAC
• Poles: 3
• Wire Range: 14 - 1/0 AWG
• Metric Wire Range: 2.5 - 50 mm squared
• Material: Steel with Cu/Al wire compatibility
• Type: KD Short Stud
• Quantity per Kit: 3 lugs
• Compatible Breaker Type: RC Molded Case Circuit Breaker
• Frame: F-frame
• UPC: 786679420706
• Made in USA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: 3TA100FB
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Lug Terminal Kit
• Family : Series C
• Type : C
• Voltage : 600VAC
• Amperage : 100
• Poles : 3
• MCM Size : 106
• Barrels : 1
• Metal Type : Aluminum
• Compatible Frames : FB

Product Data

• UPC : 786679420706
• GTIN : 00786679420706
• Country of Origin : United States
• Dimensions : 4 in x 2 in x 2 in (Length/Depth x Height x Width)
• Weight : 4
• Standards : UL Listed
• Certification : UL Listed
• Wire Size : AWG 14 to AWG 1/0
