Product Info
- Manufacturer:Siemens
- Sub-Category:Overload Relay
Description
3RU1126-4CB0
3RU1126-4CB0 is a Siemens thermal overload relay designed for motor protection with an adjustable current range of 17 to 22 amps.
This Siemens Sirius 3-pole overload relay features Class 10 tripping and phase loss sensitivity, suitable for protecting three-phase motors. It mounts on contactors with screw terminals and is sized S0 for compact installation. The relay includes manual/automatic reset options, switching position indication, a test function, and a stop button, with an integrated sealable cover for added security.
- Key Specifications
- Adjustable Amperage: 17 to 22 A
- Number of Poles: 3
- Trip Class: 10
- Mounting Type: Contactor mounting with screw terminals
- Size: S0 frame
- Phase Loss Sensitivity: Yes
- Auxiliary Contacts: 1NO, 1NC
- Power Rating: 11 kW
- Operating Temperature Range: -20 to 70 °C
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 3RU1126-4CB0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Overload Relay
- Relay Style : Thermal
- Amperage Maximum : 22
- Amperage Minimum : 17
Product Data
- UPC : 786679308042
- GTIN : 00786679308042
- Weight : 10
