Description
3RT1026-1DB44-0KV0
3RT1026-1DB44-0KV0 is a Siemens Sirius 3-pole, 3-phase contactor designed for motor control applications. This contactor features a 24VDC coil and is rated for 25A at 600V, making it suitable for demanding industrial environments.Engineered for reliable switching of electric motors, the 3RT1026-1DB44-0KV0 offers robust performance with a compact design. It includes 2 NO and 2 NC auxiliary contacts, screw terminal connections, and a built-in varistor for surge protection. The contactor is part of the Sirius S0 frame series and conforms to IEC standards for motor control.
- 3 Pole, 3-Phase
- 25A AC-3 Rating
- 600V Maximum Voltage
- 24VDC Coil Voltage
- Screw Terminal Mounting
- 2 NO + 2 NC Auxiliary Contacts
- IEC 60947-4-1 Compliance
- S0 Frame Size
- Built-in Varistor
Specifications
- Part Number: 3RT1026-1DB44-0KV0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Sirius
- Type : 3RT10
- Voltage : 600
- Amperage : 25
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 24
- Coil Voltage Minimum : 24
Product Data
- Weight : 1
