Description
3RT1025-3XB40-0LA2
3RT1025-3XB40-0LA2 is a Siemens SIRIUS traction contactor designed for AC-3 motor control applications with 7.5 kW rated power at 400V.
This 3-pole contactor features solid-state control with integrated varistor surge suppression and spring-type cage clamp terminals. The unit operates on 24V DC control voltage with an operating range factor of 0.7 to 1.25 times the rated supply voltage. It is certified to IEC 60947 and EN 60947 standards and suitable for both AC and DC operation in industrial motor switching applications.
- Rated Current: 17 A at AC-3, 400V
- Power Rating: 7.5 kW at 400V
- Control Voltage: 24V DC
- Number of Poles: 3
- Frame Size: S0
- Terminal Type: Spring-type cage clamp connection
- Surge Suppression: Integrated varistor
- Standards: IEC 60947, EN 60947 (VDE 0660), UL 508
- Operating Range: 0.7 to 1.25 times Us
- Contact Configuration: 3 NO main contacts
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: 3RT1025-3XB40-0LA2
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Sirius
- Type : 3RT10
- Voltage : 600
- Amperage : 16
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 24
- Coil Voltage Minimum : 24
Product Data
- Weight : 1
