Description
3RT1017-2KB48-3LA0
3RT1017-2KB48-3LA0 is a Siemens Sirius power contactor designed for AC-3 motor control applications with reliable switching performance in industrial environments. This 3-pole contactor features a compact S00 frame size and is rated for 12A at 5.5 kW / 400V, making it suitable for controlling 3-phase motors and similar loads. The unit operates on 24V DC coil voltage and includes cage-clamp terminal connections rated 0.7 to 1.25 times the rated voltage, with integrated varistor protection for enhanced reliability. An auxiliary switch block provides 1 NO and 3 NC contacts for signaling and interlock applications. The contactor conforms to IEC 60947-4-1 standards and is designed for safe, efficient motor control in demanding industrial settings.
- Rated Current: 12A AC-3
- Power Rating: 5.5 kW at 400V
- Poles: 3-pole
- Coil Voltage: 24V DC
- Frame Size: S00
- Terminal Type: Cage-clamp connection
- Auxiliary Contacts: 1 NO + 3 NC
- Varistor Protection: Integrated
- Standards: IEC 60947-4-1
Specifications
- Part Number: 3RT1017-2KB48-3LA0
- Manufacturer : Siemens
- Brand : Siemens
- Category : Motor Control
- Item Subcategory : Contactor
- Family : Sirius
- Type : 3RT10
- Voltage : 600
- Amperage : 12
- Phase : 3
- Poles : 3
- Coil Voltage Maximum : 24
- Coil Voltage Minimum : 24
Product Data
- Weight : 5
