Product Info
- Manufacturer:Eaton
- Sub-Category:Rating Plug
Description
16RES12T
16RES12T is a Cutler Hammer circuit breaker rating plug rated for 1200 Amps, compatible with Series G and Series C molded case circuit breakers.This rating plug is designed for use with Frame J and K breakers, supporting a maximum breaker current of 1600 Amps. It is compatible with DIGITRIP, RMS310, and RES trip units, providing accurate current sensing and metering for reliable breaker performance.
- Key Specifications
- Amperage: 1200A rating plug
- Compatible Breaker Frame: J-K
- Series: G and C
- Maximum Breaker Current: 1600A
- Trip Unit Compatibility: DIGITRIP, RMS310, RES
- Type: Rating Plug accessory
- Manufacturer: Cutler Hammer (Eaton)
- Mounting: Molded case circuit breaker accessory
- Interrupt Rating: Matches breaker frame rating
- Application: Current sensing and metering
Specifications
- Part Number: 16RES12T
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Rating Plug
- Family : Series G
- Type : 16RES
- Amperage : 1200
- Frame Size : 1200
- Amperage Maximum : 1200
- Amperage Minimum : 1200
- Compatible Frames : RD,RDC,CRD,CRDC,RGH,RGC,RW,RWC
- Trip Type : DIGITRIP,RMS310,RES
Product Data
- UPC : 786679581209
- GTIN : 00786679581209
- Country of Origin : United States
- Dimensions : 5 in x 1.5 in x 1.8 in (Length/Depth x Height x Width)
- Weight : 0.1
- Certification : UL Listed CSA Certified
