- Manufacturer:Schneider Electric
Description
XVBL35
XVBL35 is a Square D 35 Amp 2-Pole bolt-on circuit breaker designed for reliable electrical protection in residential and commercial applications.This circuit breaker features a 35 Ampere current rating, 120/240 Volt AC system voltage, and a 2-pole configuration. It is part of the QO series with a bolt-on mounting type and a 10,000 A interrupting rating. The breaker uses a thermal magnetic trip unit and is HACR rated for HVAC equipment compatibility. It supports copper or aluminum wire sizes from AWG 8 to AWG 2 and includes box lug electrical connections.
- Key Specifications
- Amperage: 35 Amps
- Voltage: 120/240 Volts AC
- Number of Poles: 2
- Mounting Type: Bolt-on
- Interrupt Rating: 10,000 Amps
- Series/Frame: QO
- Trip Unit: Thermal Magnetic
- Certifications: UL Listed, ANSI Certified, HACR Rated
- Wire Size: AWG 8 to AWG 2 (Copper/Aluminum)
- Electrical Connection: Box Lugs
- Part Number: XVBL35
- Manufacturer : Schneider Electric
- Brand : Schneider Electric
- UPC : 38911084414
- GTIN : 03389110844146
- Country of Origin : Czechia
- Weight : 0.58
