XTPRP16BC1 - Eaton Manual Motor Protector 0.16A 3P Class 10 45mm Frame

XTPRP16BC1

XTPRP16BC1 is an Eaton IEC motor control manual motor protector designed for thermal-magnetic protection of three-phase motors with adjustable overload settings. This compact 45 mm frame device features a rotary manual disconnect, Class 10 trip characteristic, and fixed magnetic short-circuit trip capability suitable for group motor installations and Type E self-protected combination starters. Key Specifications

• Amperage Rating: 0.16 A
• Adjustable Thermal Range: 0.1 - 0.16 A
• Magnetic Trip Response: 2.2 A
• Poles: 3-Phase
• Frame Size: 45 mm (Frame B)
• Trip Type: Thermal-Magnetic, Class 10
• Mounting: DIN Rail
• Terminal Type: Screw
• Short-Circuit Current Rating: 50 kA @ 600 V AC
• Control Type: Rotary Manual Disconnect
• Certifications: UL Listed, CSA Certified, NEC 430, CEC Rule 28-206
• Country of Origin: Germany

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: XTPRP16BC1
• Manufacturer : Eaton
• Brand : Eaton
• Amperage : 0.16

Product Data

• UPC : 786685691084
• GTIN : 04015082653309
• Country of Origin : Germany
• Dimensions : 2 in x 4 in x 4 in (Length/Depth x Height x Width)
• Weight : 0.5
• Certification : ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, UL Listed
