XTPR2P5BC1 - Eaton 2.5A Manual Motor Protector, Class 10 Trip, 3-Pole, 45mm Frame, Rotary Handle, DIN Rail Mount

XTPR2P5BC1

XTPR2P5BC1 is an Eaton manual motor protector adjustable from 1.6 to 2.5 amps with Class 10 trip characteristic and rotary ON/OFF handle.This motor protector features a 45 mm frame size, 3-pole configuration, and mounts easily on a standard 35 mm DIN rail. It provides thermal-magnetic overload and short-circuit protection with built-in heater and magnetic trip elements. The device includes phase loss sensitivity, ambient temperature compensation per IEC/EN 60947, and fixed short-circuit trip at 14 times the overload setting. It is UL Listed and CSA Certified for reliable motor control applications.

Key Specifications
• Amperage Range: 1.6 to 2.5 A adjustable
• Trip Class: 10 (trips within 10 seconds)
• Poles: 3-pole
• Frame Size: 45 mm (Frame B)
• Mounting Type: 35 mm DIN rail
• Trip Unit: Thermal-magnetic with rotary ON/OFF handle
• Interrupt Rating: Fixed short-circuit trip at 14x overload setting
• Certifications: UL Listed, CSA Certified
• Phase Loss Sensitivity and Ambient Temperature Compensation
• Terminal Type: Screw terminals

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: XTPR2P5BC1
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Part And Accessory
• Amperage : 2.5
• Temp Rating : -13–158 °F (-25–70 °C)

Product Data

• UPC : 01508265337
• GTIN : 04015082653378
• Country of Origin : Germany
• Dimensions : 4 in x 2 in x 4 in (Length/Depth x Height x Width)
• Weight : 0.4
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, UL Listed
