Product Info
- Manufacturer:Eaton
- Sub-Category:Motor Starter
Description
XTPR032BC1
XTPR032BC1 is an Eaton B-Frame motor protector designed for motor control applications with a 32 ampere rating and rotary ON/OFF operation.This Eaton IEC motor control PR series manual motor protector features a 45 mm frame size, Class 10 trip type, and 3 poles, suitable for 690V applications with screw connection type and NEMA 1/2/IP20 enclosure.
- Amperage Rating: 32A
- Voltage Rating: 690V
- Poles: 3
- Frame Size: B-Frame, 45 mm
- Trip Type: Class 10
- Operation: Rotary ON/OFF
- Connection Type: Screw
- Enclosure Rating: NEMA 1/2, IP20
- Interrupt Rating: Not specified
- Certifications: UL 508, CSA Std. C22.2
- Country of Origin: Germany
Specifications
- Part Number: XTPR032BC1
- Manufacturer : Eaton
- Brand : Eaton
- Category : Motor Control
- Item Subcategory : Motor Starter
- Voltage : 1000
- Amperage : 32
- Phase : 3
- Poles : 3
- AIC rating : 14kA@1000V
- Connection : Bolt-On
- Functions : I - Instantaneous
- Protection : Magnetic Only
Product Data
- UPC : 4015081531134
- GTIN : 04015081531134
- Country of Origin : Germany
- Dimensions : 3.7 in x 3.66 in x 1.77 in (Length/Depth x Height x Width)
- Weight : 0.5 lb
- Certification : ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, UL Listed
