XTPB020BC1 - Eaton Moeller Manual Motor Protector 16-20A Class 10 DIN Rail Mount

XTPB020BC1

XTPB020BC1 is an Eaton Moeller manual motor protector designed for motor control applications with adjustable current settings from 16 to 20 amps and Class 10 trip characteristic.

This motor protector features a pushbutton ON/OFF operation, mounts on a standard 35mm DIN rail, and includes a Class 10 adjustable bimetallic overload relay with fixed magnetic short-circuit trip capability. It is suitable for use as a thermal magnetic circuit breaker and is commonly paired with XTCE contactors for self-protected motor starters. The unit has screw terminals and complies with IEC/EN60947 standards, with certifications including ATEX, CE, CSA, and UL 508. It is a Frame B size (45 mm) device designed for motors with full load amperage up to 32A.

• Adjustable current range: 16 to 20 amps
• Trip class: 10 (trips within 10 seconds or less)
• Mounting type: 35mm DIN rail
• Operation: Pushbutton ON/OFF
• Terminals: Screw type
• Frame size: 45 mm (Frame B)
• Short circuit trip: Fixed magnetic
• Certifications: ATEX, CE, CSA, UL 508
• Compliance: IEC/EN60947
• Country of origin: Germany

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: XTPB020BC1
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Control Part And Accessory

Product Data

• UPC : 015082833835
• Country of Origin : Germany
• Dimensions : 2 in x 3.75 in x 3.75 in (Length/Depth x Height x Width)
• Weight : 0.72 lb
• Certification : ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, UL Listed
