XTMC9A01T - Eaton XT IEC Mini Contactor 8.8A 24VAC 3-Pole

XTMC9A01T

XTMC9A01T is an Eaton XT IEC series miniature contactor designed for full voltage non-reversing motor control applications.

This compact 45 mm mini contactor features an 8.8 ampere continuous rating with 24 VAC coil voltage at 50-60 Hz operation. The three-pole configuration with one normally closed auxiliary contact provides reliable control for fractional to 5 horsepower motors across multiple voltage ratings (115V, 200V, 230V, 460V, and 575V single or three-phase). Screw terminals ensure secure wire connections, and the unit is rated for 20A auxiliary contact capacity. The non-reversing design makes it ideal for light-duty applications including hoisting, packaging, material handling, heating, lighting, and automation systems.

• Amperage Rating: 8.8A continuous
• Coil Voltage: 24 VAC, 50-60 Hz
• Number of Poles: Three-pole
• Auxiliary Contacts: 1 NC (normally closed)
• Frame Size: 45 mm mini
• Series: XT IEC
• Operation: Full voltage non-reversing
• Terminal Type: Screw terminals
• Horsepower Rating: 0.5, 1, 1.5, 2, 3, 5 hp
• Certifications: UL Listed, CSA Certified, RoHS Compliant, CE Marked
• Standards: IEC 60947, EN 60947
• Weight: 0.3 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This XT IEC Mini Contactor includes a 24 VAC coil.

Specifications

• Part Number: XTMC9A01T
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Contactor
• Configuration : Non-Reversing
• Aux Contacts : 1 NC
• Frequency : 50 Hz

Product Data

• UPC : 786685363745
• GTIN : 04015080204022
• Country of Origin : Germany
• Dimensions : 2.5 in x 2 in x 2.5 in (Length/Depth x Height x Width)
• Weight : 0.3
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
