XTCE250L22A - Cutler Hammer 250A 3-Pole IEC Non-Reversing Contactor, Frame L, 110V Coil

XTCE250L22A

XTCE250L22A is a Cutler Hammer 3-pole IEC non-reversing contactor rated for 250 amps with a 110V coil. XTCE250L22A features a full voltage type design suitable for motor control applications, with a Frame L size and a maximum voltage rating of 250V. It supports up to 250 HP at various voltages and frequencies, making it ideal for heavy-duty industrial use. The contactor includes 2 normally open and 2 normally closed auxiliary contacts for flexible control configurations.

Key Specifications
• Amperage Rating: 250A
• Number of Poles: 3 (Three-pole)
• Coil Voltage: 110V (50/60 Hz)
• Maximum Voltage: 250V
• Frame Size: L
• Type: Full Voltage Non-Reversing Contactor
• Auxiliary Contacts: 2 NO + 2 NC
• HP Rating: Up to 250 HP (3-phase at 200, 230, 460, 575 V)
• Mounting: Panel Mount
• Interrupt Rating: Per IEC standards
• Certifications: Eaton / Cutler Hammer standards

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 250 VDC coil.

Specifications

• Part Number: XTCE250L22A
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Voltage : 600
• Amperage : 250
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Aux Contacts : 2 NO + 2 NC
• Coil Voltage Maximum : 250
• Coil Voltage Minimum : 110
• Frequency : 50 Hz

Product Data

• UPC : 001508208201
• Dimensions : 8.18897638 in x 7.08661417 in x 5.51181102 in (Length/Depth x Height x Width)
• Weight : 0.5070632
