XTCE225H22TD - Cutler Hammer 225A 600V 3 Pole IEC Contactor, 24-27V Coil, Frame H, Non-Reversing

XTCE225H22TD

XTCE225H22TD is a Cutler Hammer XT Series IEC contactor designed for motor control applications with a 225 amp rating and 3 poles.This contactor features a 24-27 VDC coil voltage, supports up to 600V, and is a non-reversing full voltage type with Frame H construction. It is suitable for heavy-duty motor control with horsepower ratings up to 200 HP (3 phase at various voltages). The device includes 2 normally open and 2 normally closed auxiliary contacts and is UL listed for safety and reliability.

• Amperage Rating: 225A
• Voltage Rating: 600V
• Coil Voltage: 24-27 VDC
• Number of Poles: 3
• Frame: H
• Type: Non-Reversing Full Voltage Contactor
• Auxiliary Contacts: 2NO + 2NC
• Horsepower Rating: Up to 200 HP (3PH @ 200-600V)
• Mounting: Panel/DIN Rail Compatible
• Certifications: UL Listed
• Interrupt Rating: Suitable for motor control applications

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This includes a 27 VDC coil.

Specifications

• Part Number: XTCE225H22TD
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 27
• Coil Voltage Minimum : 24

Product Data

• UPC : 401508136328
• Dimensions : 6.22047244 in x 7.08661417 in x 5.51181102 in (Length/Depth x Height x Width)
• Weight : 0.61729433 lb
