Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Contactor
Description
XTCE225H22A
XTCE225H22A is a Cutler Hammer full voltage IEC contactor designed for motor control applications with a 225 amp rating and 3 poles.This contactor features a 225 amp amperage rating, supports coil voltages of 100 Vac 50 Hz and 120 Vac 60 Hz, and is suitable for motors up to 200 hp at voltages ranging from 200 to 600 V. It includes 2 normally open and 2 normally closed auxiliary contacts, is part of the XT IEC Series Frame H, and mounts on DIN rail or panel. The device is rated for 50-60 Hz frequency and offers reliable switching performance for industrial motor control.
- Key Specifications
- Amperage Rating: 225 A
- Number of Poles: 3 (Three-pole)
- Coil Voltage: 100 Vac 50 Hz, 120 Vac 60 Hz
- Horsepower Rating: Up to 200 hp (3-phase, 200-600 V)
- Auxiliary Contacts: 2 NO + 2 NC
- Mounting Type: DIN Rail or Panel Mount
- Series/Frame: XT IEC Series, Frame H
- Frequency Rating: 50-60 Hz
- Type: Full Voltage Non-Reversing Contactor
- Interrupt Rating: Standard for XT IEC Series
- Part Number: XTCE225H22A
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Motor Control
- Item Subcategory : Contactor
- Family : XT Series
- Type : XTCE225H
- Voltage : 600
- Amperage : 225
- Phase : 3
- Poles : 3
- Configuration : Non-Reversing
- Aux Contacts : 2 NO + 2 NC
- Coil Voltage Maximum : 120
- Coil Voltage Minimum : 100
- Frequency : 50 Hz
- UPC : 401508136324
- Dimensions : 10 in x 8.5 in x 6 in (Length/Depth x Height x Width)
- Weight : 6.5 lb
Additional Information
This IEC Non-Reversing Contactor includes a 100 VAC coil.
