XTCE072DS1A - Cutler Hammer XT IEC 72A 3-Pole 110-120V Contactor

XTCE072DS1A

XTCE072DS1A is an Eaton XT IEC series full voltage non-reversing contactor rated for 72 amperes at 600 VAC, designed for reliable motor control and protection across a wide range of industrial applications. This side-mounted contactor features a 110-120 VAC 50/60 Hz coil, three poles with 1 NO and 1 NC contact configuration, and screw terminals for secure connections. The unit is rated for motors up to 5, 10, 15, 20, 25, 50, and 60 horsepower depending on voltage and phase configuration (1/3PH at 115, 200, 230, 460, and 575 volts). Built to Frame D specifications with a 55 mm frame size, this contactor operates at 50-60 Hz frequency and is suitable for controlling motors, compressors, pumps, and resistive loads.

• Amperage Rating: 72 A continuous
• Voltage: 600 VAC, 110-120 VAC coil
• Number of Poles: 3
• Contact Configuration: 1 NO, 1 NC
• Mounting: Side-mounted
• Frame Size: Frame D, 55 mm
• Frequency: 50-60 Hz
• Terminals: Screw terminals
• Operation: Full voltage non-reversing
• Series: XT IEC
• Certifications: CSA Certified, UL Listed, EN 60947, IEC 60947
• Weight: 2.125 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This includes a 120 VAC coil.

Specifications

• Part Number: XTCE072DS1A
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Voltage : 600
• Amperage : 72
• Phase : 3
• Poles : 3
• Coil Voltage Maximum : 120
• Coil Voltage Minimum : 120

Product Data

• UPC : 786685365183
• Country of Origin : Germany
• Dimensions : 1 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 1
• Certification : CSA Certified,UL Listed,IEC 60947,EN 60947
