XTCE050D00A - Cutler Hammer 50A 3-Pole IEC Contactor D Frame 690VAC DIN Rail Mount

XTCE050D00A

XTCE050D00A is a Cutler Hammer 3-pole IEC contactor designed for motor control applications with a 50 ampere rating and D frame size. XTCE050D00A features a 50A maximum load current, supports voltages up to 690 VAC, and is suitable for use with motors up to 50 HP depending on voltage. It mounts on DIN rails for easy panel installation and operates at 50/60 Hz frequency. This contactor is part of Eaton's XT series, known for reliable motor control and protection.

Key Specifications
• Amperage Rating: 50A
• Voltage Rating: Up to 690 VAC
• Number of Poles: 3 (3-Pole)
• Frame Size: D Frame
• Mounting Type: DIN Rail
• Frequency: 50/60 Hz
• Maximum Motor HP: Up to 50 HP (depending on voltage)
• Series: Eaton XT IEC Contactor
• Interrupt Rating: Standard for XT series (consult datasheet)
• Trip Unit: Non-reversing contactor
• Certifications: Eaton certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 110 VAC coil.

Specifications

• Part Number: XTCE050D00A
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE050D
• Voltage : 600
• Amperage : 50
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 15 hp HP @ 3 Phase - 240V 20 hp HP @ 3 Phase - 480V 40 hp
• Configuration : Non-Reversing
• Aux Contacts : 0 NO + 0 NC
• Coil Voltage Maximum : 120
• Full Load Amps : Full Load Amps-Inductive 50A Full Load Amps-Resistive 80A
• Coil Voltage Minimum : 120
• Frequency : 50 Hz

Product Data

• UPC : 783087817852
• GTIN : 04015082778279
• Country of Origin : Romania
• Dimensions : 6 in x 2 in x 4.75 in (Length/Depth x Height x Width)
• Weight : 2.12 lb
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
