XTCE032C10T - Cutler Hammer 32A 3 Pole 24V AC IEC Motor Contactor, 10HP 230V, 20HP 460V, Frame C

XTCE032C10T

XTCE032C10T is a 32 amp, 3 pole IEC motor contactor from Cutler Hammer designed for motor control applications.This contactor features a 24 VAC coil operating at 50/60 Hz, supports 10 HP at 230V and 20 HP at 460V, and includes 1 normally open auxiliary contact. It has a 45 mm frame size and is suitable for screw or DIN rail mounting. The device is UL listed, CSA certified, CE marked, and complies with IEC 60947 standards.

• Amperage rating: 32A
• Voltage rating: 24 VAC coil, 50/60 Hz
• Horsepower rating: 10 HP at 230V, 20 HP at 460V
• Number of poles: 3
• Contact configuration: 1 normally open (NO) auxiliary contact
• Frame size: 45 mm (Frame C)
• Mounting type: Screw terminals or DIN rail
• Interrupt rating: IEC 60947 compliant
• Operation: Non-reversing
• Certifications: UL Listed, CSA Certified, CE Marked
• Application: Motor and power control equipment

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 24 VAC coil.

Specifications

• Part Number: XTCE032C10T
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE032C
• Voltage : 4
• Amperage : 32
• Phase : 3
• Poles : 3
• Temp Rating : -13–158 °F (-25–70 °C)
• Horse Power : HP @ 3 Phase - 208V 10 hp HP @ 3 Phase - 240V 10 hp HP @ 3 Phase - 480V 20 hp
• Configuration : Non-Reversing
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 24
• Full Load Amps : Full Load Amps-Inductive 32A Full Load Amps-Resistive 45A
• Coil Voltage Minimum : 24
• Frequency : 50 Hz

Product Data

• UPC : 015082772646
• Country of Origin : Romania
• Dimensions : 4 in x 2 in x 3.5 in (Length/Depth x Height x Width)
• Weight : 0.5
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
