XTCE032C10C - Cutler Hammer 32A 600V 3 Pole IEC Motor Contactor with 480V Coil

XTCE032C10C

XTCE032C10C is a Cutler Hammer XT Series motor contactor designed for 3-phase motor control applications.This 3 pole contactor features a 32 ampere rating and supports up to 600 volts AC. It includes a 480 VAC coil and 1 normally open auxiliary contact. The device conforms to IEC 60947 standards and is suitable for full voltage non-reversing motor starting. It is part of the XT IEC series with Frame C construction.

Key Specifications
• Amperage: 32A
• Voltage Rating: 600 VAC max
• Coil Voltage: 480 VAC
• Poles: 3
• Mounting Type: Panel mount (IEC Frame C)
• Auxiliary Contacts: 1 NO
• Standards: IEC 60947 compliant
• Type: Full voltage non-reversing contactor
• Series: XT IEC
• Frame: C
• Frequency: 50/60 Hz
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Additional Information

This IEC Non-Reversing Contactor includes a 412 VAC coil.




Specifications

• Part Number: XTCE032C10C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE032C
• Voltage : 600
• Amperage : 32
• Phase : 3
• Poles : 3
• Temp Rating : -13–158 °F (-25–70 °C)
• Horse Power : HP @ 3 Phase - 208V 10 hp HP @ 3 Phase - 240V 10 hp HP @ 3 Phase - 480V 20 hp
• Configuration : Non-Reversing
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 480
• Full Load Amps : Full Load Amps-Inductive 32A Full Load Amps-Resistive 45A
• Coil Voltage Minimum : 480
• Frequency : 50 Hz



Product Data

• UPC : 401508277263
• Country of Origin : Romania
• Dimensions : 3.425 in x 3.898 in x 1.85 in (Length/Depth x Height x Width)
• Weight : 0.9 lb
• Temp Rating : -13–158 °F (-25–70 °C)
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
