XTCE015B10C - Cutler Hammer 15A 3 Pole IEC Contactor 480V DIN Rail Mount Frame B

XTCE015B10C

XTCE015B10C is a Cutler Hammer 15 Amp, 3 Pole IEC contactor designed for motor control applications with DIN rail mounting.This contactor supports up to 480 VAC operation, features a 1NO auxiliary contact, and belongs to the XT IEC Series Frame B. It is suitable for controlling motors up to 10 HP at 460V and 3 HP at 230V, operating at 50-60 Hz frequencies. The compact design measures approximately 2" x 1.85" x 3.43" (HxWxD) and is rated for industrial use with reliable switching performance.

Key Specifications
• Amperage: 15 A
• Voltage: 415-480 VAC
• Poles: 3 Pole (3PST-NO)
• Mounting Type: DIN Rail
• Frame: XT IEC Series Frame B
• Auxiliary Contact: 1NO
• Horsepower Rating: 3 HP @ 230V, 10 HP @ 460V
• Frequency: 50-60 Hz
• Dimensions: 2" x 1.85" x 3.43" (HxWxD)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 415 VAC coil.

Specifications

• Part Number: XTCE015B10C
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE015B
• Voltage : 600
• Amperage : 15
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 5 hp HP @ 3 Phase - 240V 5 hp HP @ 3 Phase - 480V 10 hp
• Configuration : Non-Reversing
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 480
• Full Load Amps : Full Load Amps-Inductive 15A Full Load Amps-Resistive 22A
• Coil Voltage Minimum : 480
• Compatible Frames : PDG,PDG Frame 4
• Frequency : 50 Hz

Product Data

• UPC : 01508290061
• GTIN : 04015082900618
• Country of Origin : Romania
• Dimensions : 3 in x 2 in x 3 in (Length/Depth x Height x Width)
• Weight : 0.3
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
