XTCE015B01TD - Cutler Hammer 15A 24VDC 3-Pole Full Voltage Non-Reversing Contactor XT IEC Series Frame B

XTCE015B01TD

XTCE015B01TD is a Cutler Hammer XT IEC series full voltage non-reversing contactor with a 15 ampere rating and 24 VDC coil voltage.

This three-pole contactor features a 45 mm frame size and screw terminals, designed for motor control applications. It supports horsepower ratings up to 10 hp at 460/575 V 3-phase and includes 1 normally closed (NC) contact. The device is UL listed, CSA certified, RoHS compliant, and CE marked, meeting IEC 60947 and EN 60947 standards.

Key Specifications
• Amperage Rating: 15 A
• Coil Voltage: 24 VDC
• Number of Poles: Three-pole
• Contact Configuration: 1 NC
• Frame Size: 45 mm (Frame B)
• Type: Full voltage non-reversing contactor
• Horsepower Rating: Up to 10 hp (460/575 V 3-phase)
• Terminals: Screw terminals
• Certifications: UL Listed, CSA Certified, CE Marked
• Standards: IEC 60947, EN 60947
• Series: XT IEC

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 24 VDC coil.

Specifications

• Part Number: XTCE015B01TD
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Contactor
• Family : XT Series
• Type : XTCE015B
• Voltage : 600
• Amperage : 15
• Phase : 3
• Poles : 3
• Horse Power : HP @ 3 Phase - 208V 5 hp HP @ 3 Phase - 240V 5 hp HP @ 3 Phase - 480V 10 hp
• Configuration : Non-Reversing
• Aux Contacts : 1 NC
• Coil Voltage Maximum : 24
• Coil Voltage Minimum : 24
• Compatible Frames : PDG,PDG Frame 4

Product Data

• UPC : 01508290108
• GTIN : 04015082901080
• Country of Origin : Romania
• Dimensions : 3 in x 2 in x 3 in (Length/Depth x Height x Width)
• Weight : 0.5 lb
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
