XTCE007B10T - Eaton 7 Amp 24 Volt 3 Pole IEC Contactor B-Frame Non-Reversing

XTCE007B10T

XTCE007B10T is a 3 pole IEC rated contactor from Eaton designed for motor control applications with a 7 amp rating and 24 volt coil.XTCE007B10T features a B-frame size, screw or DIN rail mounting, and includes one normally open auxiliary contact. It supports motor horsepower ratings up to 3 HP at 460V and 2 HP at 230V, making it suitable for a variety of industrial motor control tasks. This non-reversing contactor meets IEC, UL, CSA, CCC, and CE certifications, ensuring global compliance and reliability.

Key Specifications
• Amperage: 7 Amp AC-3 rating
• Coil Voltage: 24 Volt AC, 50/60 Hz
• Number of Poles: 3 Pole
• Mounting Type: Screw or DIN Rail
• Frame Size: B-Frame (45 mm)
• Auxiliary Contacts: 1 Normally Open (N.O.)
• Horsepower Ratings: 3 HP at 460V, 2 HP at 230V
• Interrupt Rating: IEC Rated
• Type: Full Voltage Non-Reversing Contactor
• Certifications: IEC, UL, CSA, CCC, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This IEC Non-Reversing Contactor includes a 24 VAC coil.

Specifications

• Part Number: XTCE007B10T
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 2
• Amperage : 7
• Phase : 3
• Poles : 3
• Configuration : Non-Reversing
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 24
• Coil Voltage Minimum : 24
• Frequency : 50 Hz

Product Data

• UPC : 786685363400
• GTIN : 04015082765545
• Country of Origin : Romania
• Dimensions : 4.92125984 in x 2.67716535 in x 1.77165354 in (Length/Depth x Height x Width)
• Weight : 0.5
• Certification : CE, CSA, EN 60947, IEC 60947, RoHS, UL Listed
