XTAE018C10TD5E020 - Cutler Hammer IEC Non-Reversing Starter 18A 24-27VDC C Frame

XTAE018C10TD5E020

XTAE018C10TD5E020 is an Eaton XT IEC electronic motor starter designed for full voltage non-reversing control applications with DC coil operation. This compact C frame starter delivers reliable motor control in industrial and commercial environments requiring 24-27 VDC control voltage with 18 ampere rated capacity. The unit features a 45 mm frame size and includes one normally open (1NO) auxiliary contact for flexible control logic integration. Screw terminal connections accommodate standard wiring practices for quick installation and maintenance. The integrated XTOE overload relay provides adjustable protection across the 4-20 ampere range, safeguarding connected motors from thermal overload conditions. This starter supports AC control inputs from 12V to 600V at 50/60 Hz, enabling versatile integration into existing control systems.

• Amperage Rating: 18 A
• Coil Voltage: 24-27 VDC
• Frame Size: C (45 mm)
• Auxiliary Contacts: 1 Normally Open (1NO)
• Overload Relay Type: XTOE
• Overload Range: 4-20 A
• Terminal Type: Screw Terminals
• AC Control Voltage: 12V to 600V 50/60 Hz
• Starter Type: Full Voltage Non-Reversing
• Weight: 3.00 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Non-Reversing

Specifications

• Part Number: XTAE018C10TD5E020
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Motor Control
• Item Subcategory : Motor Starter
• Family : XT Series
• Type : XTAE
• Voltage : 600
• Amperage : 18 Amp
• Phase : 3
• Poles : 3
• Full Load Amp Minimum : 4A
• Full Load Amp Maximum : 20A
• Aux Contacts : 1 NO
• Coil Voltage Maximum : 24 VDC
• Full Load Amps : 4-20 Amp
• Coil Voltage Minimum : 24

Product Data

• UPC : 786685420585
• GTIN : 00786685420585
• Country of Origin : United States
• Dimensions : 5.5 in x 5.37 in x 1.38 in (Length/Depth x Height x Width)
• Weight : 2.35
