XT2LU3125FYD000XXX - ABB 125A 600V 3 Pole Molded Case Circuit Breaker 100kA Interrupt Rating

XT2LU3125FYD000XXX

XT2LU3125FYD000XXX is a 3-pole molded case circuit breaker from ABB rated for 125 amperes at 600 volts AC, designed for reliable thermal-magnetic protection in industrial and commercial power distribution applications.

This ABB Tmax XT2 series breaker features a compact molded case design with fixed thermal-magnetic trip unit protection. The unit is UL489 and cUL489 listed, meeting industry safety standards for low voltage circuit protection. It includes mounting hardware, terminal hardware, phase barriers, and an insulation backplate for safe installation on standard DIN rail or panel mounting configurations.

• Manufacturer: ABB
• Part Number: XT2LU3125FYD000XXX
• Amperage: 125 A
• Voltage Rating: 600 V AC
• Number of Poles: 3
• Interrupting Rating: 100 kA at 480 V
• Trip Unit: Thermal-Magnetic
• Frame Size: 125 A
• Certifications: UL489, cUL489
• Mechanical Life: 25,000 operations
• Dimensions: 3.54 x 3.25 x 5.12 inches (W x D x H)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: XT2LU3125FYD000XXX
• Manufacturer : ABB
• Brand : ABB
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : SACE Tmax XT
• Type : XT2LU
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LSI - Long Time, Short Time and Instantaneous Trip
• Protection : Thermal Magnetic

Product Data

• Country of Origin : United States
• Weight : 8 lb
• Standards : UL, CSA
• Certification : UL, CSA
• Wire Size : AWG 10 to AWG 2/0, Cu/Al
