Product Info
- Manufacturer:ABB
- Sub-Category:Molded Case
Description
XT2LU3100FYD000XXX
XT2LU3100FYD000XXX is a 3 pole molded case circuit breaker from ABB's XT2 series, designed for reliable protection in commercial and industrial power distribution systems. This breaker features a 100A current rating, 600VAC voltage rating, and is built on the XT2 frame for robust performance. It utilizes a fixed thermal-magnetic trip unit for effective overload and short circuit protection. The breaker is suitable for fixed mounting and is UL listed for safety and compliance. Its compact design and high interrupting capacity make it ideal for a wide range of applications. Key Specifications
- Part Number: XT2LU3100FYD000XXX
- Manufacturer: ABB
- Series/Frame: XT2
- Number of Poles: 3
- Rated Current: 100A
- Rated Voltage: 600VAC
- Mounting Type: Fixed
- Interrupt Rating: 100kA at 480VAC
- Trip Unit: Fixed Thermal-Magnetic
- Certifications: UL Listed
- Dimensions: 5.12" H x 3.54" W x 3.25" D
- Application: Commercial and Industrial Power Distribution
Specifications
- Part Number: XT2LU3100FYD000XXX
- Manufacturer : ABB
- Brand : ABB
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : SACE Tmax XT
- Type : XT2LU
- Voltage : 600
- Amperage : 100
- Phase : 3
- Poles : 3
- Connection : Bolt-On
- Functions : LSI - Long Time, Short Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- Country of Origin : United States
- Weight : 8 lb
- Standards : UL, CSA
- Certification : UL, CSA
- Wire Size : AWG 10 to AWG 2/0, Cu/Al
