Product Info
- Manufacturer:Eaton
- Sub-Category:Standard enclosures and junction boxes
Description
XLHZTMP4035
XLHZTMP4035 is an Eaton Crouse-Hinds series Ex-CELL mounting plate designed for industrial enclosure applications. This zinc coated steel mounting plate is engineered for use with 406 x 355 x 203 mm enclosure sizes and supports both vertical and horizontal configurations. The plate features a 2 mm material thickness and is rated for electrical applications up to 690V AC/DC with current capacity up to 400A. It is suitable for hazardous location environments with ATEX and IECEx certifications including Ex eb IIC T6/5/4 Gb and Ex tb IIIC T80/95/130°C Db markings, as well as NEC 500 and NEC 505 Class I, Division 2 compliance. The enclosure operates across a standard service temperature range of -40°C to +80°C, with extended temperature capability to -60°C to +135°C when specified with the 'E' suffix. Key Specifications
- Part Number: XLHZTMP4035
- Manufacturer: Eaton
- Enclosure Size: 406 x 355 x 203 mm
- Material: Zinc coated steel
- Material Thickness: 2 mm
- Voltage Rating: 690 V AC/DC
- Current Rating: 400 A
- Terminal Cross-Section: 240 mm²
- Operating Temperature: -40°C to +80°C
- Extended Temperature: -60°C to +135°C
- Configuration: Vertical or horizontal
- Certifications: ATEX, IECEx, NEC 500, NEC 505
Specifications
- Part Number: XLHZTMP4035
- Manufacturer : Eaton
- Brand : Eaton
- Category : Enclosures
- Item Subcategory : Standard enclosures and junction boxes
- Section : Mounting plate
- Voltage : 690 V AC/DC
- Configuration : Vertical or horizontal
- Amperage Maximum : 400 A
- Operating Temperature Maximum Celsius : -40°C to +80°C
- Material : Zinc coated steel
- NEC hazardous rating : Class I, Zone 1 Class II, Division 2 Class I, Division 2
- Enclosure size : 406 x 355 x 203 mm
- Special features : Vertical or horizontal configuration
- IECEx/ATEX hazardous rating : Ex eb IIC T6/5/4 Gb; Ex tb IIIC T80/95/130°C Db
- Minimum Ambient Operating Temperature : -40°C
- Maximum Ambient Operating Temperature : +80°C
Product Data
- GTIN : 04251958140423
