Description
X8635-21
X8635-21 is an Eaton Crouse-Hinds Flexitite X Series attachable pendant pushbutton station designed for motor circuit control applications. This 2-button, 1-speed station is rated for 20 amps and 460 VAC, with a power rating of 2 HP at 230 VAC. The unit features a steel-reinforced neoprene enclosure that provides safety insulation to meet OSHA requirements for enclosing live parts. It supports cable diameters from 0.555 to 0.665 inches and offers robust protection for internal switches and connectors through cushioned neoprene encapsulation.
- Manufacturer: Eaton Crouse-Hinds
- Part Number: X8635-21
- Amperage Rating: 20 A
- Voltage Rating: 460 VAC
- Power Rating: 2 HP at 230 VAC
- Number of Buttons: 2
- Speed: 1-Speed
- Enclosure Material: Steel-reinforced neoprene
- Cable Diameter Range: 0.555 to 0.665 inches
- Safety: Insulated to meet OSHA requirements
- Dimensions: 8-3/4 in L x 2-1/4 in W x 3 in D
- Application: Motor circuit control for hoists, cranes, machine tools, electromagnets
Additional Information
Please note that circuit breakers are not included with the enclosures and must be purchased separately.
Specifications
- Part Number: X8635-21
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Enclosure
- Voltage : 460
- Amperage : 20
- Material : Steel-reinforced neoprene
Product Data
- UPC : 662275161383
- Country of Origin : United States
- Dimensions : 8.75 in x 3 in x 2.25 in (Height x Length x Width)
- Weight : 2.5
