Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Trip Units & Programmers
Description
WMZS1B10
WMZS1B10 is a Cutler Hammer miniature circuit breaker rated for 10 amps, 1 pole, and 277/480 volts with a 10kA interrupt rating.This WMZS series circuit breaker features thermal magnetic trip protection with a C curve trip characteristic, suitable for protecting circuits with moderate inrush currents. It mounts on a standard 35 mm DIN rail using a spring clip and includes a color-coded status indicator window. The breaker is UL 489 and IEC/EN 60898 certified, providing reliable overcurrent protection in industrial and commercial applications.
- Amperage: 10 A
- Voltage Rating: 277/480 V AC
- Number of Poles: 1
- Interrupt Rating: 10 kA at 277 V
- Mounting Type: 35 mm DIN rail
- Trip Unit: Thermal magnetic, C curve
- Series/Frame: WMZS
- Certifications: UL 489, IEC/EN 60898, CSA
- Color-coded status indicator window
- Reverse feedable design
- IP20 finger protection
Specifications
- Part Number: WMZS1B10
- Manufacturer : Cutler Hammer
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Trip Units & Programmers
- Family : WMZS Series
- Type : WMZS
- Voltage : 480
- Amperage : 10
- Phase : 1
- Poles : 1
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 78668525845
- GTIN : 00786685258454
- Country of Origin : Spain
- Weight : 0.3
- Certification : IEC 60947-2;UL 1077;CSA Std. C22.2 No. 235;RoHS Compliant;CE Marked
