WBM31600B - Siemens Power Mod WB 1-600 A 3-Phase-1600 A Main Breaker Module

WBM31600B

WBM31600B is a Power Mod™ WB series main breaker module from Siemens, designed for service-entrance and low-voltage power distribution applications. Rated for 1600 amps in a 3-phase configuration with a bottom-feed “skinny” footprint, this module features a short-circuit interrupt rating of 65 kA, supports a voltage rating of 240 V (phase-to-phase) and includes a NEMA Type 3R galvanized steel enclosure. The bottom-feed designation (suffix “B”) indicates fixed cable entry from below, making it suitable for underground pull-through service installation. Key Specifications:

• Amperage rating: 1600 A
• Phase configuration: 3-phase
• Voltage rating: 240 V (phase to phase)
• Interrupting rating (AIC): 65 kA
• Enclosure type: NEMA Type 3R galvanized steel
• Frame series: Power Mod WB – bottom-feed (skinny) design
• Application: service-entrance main, underground feeder draft, modular metering panels

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: WBM31600B
• Manufacturer : Siemens
• Brand : Siemens
• Category : Switch
• Item Subcategory : Main Breaker Disconnect
• Family : WBM
• Type : WBM
• Amperage : 1600
• Phase : 3
• AIC rating : 65kAIC
• Nema Rating : 3R

Product Data

• UPC : 80476669859
• GTIN : 00804766698590
• Weight : 527.91 lb
