VMVL-7-J-R3-G-UNV1-S890 - Eaton Crouse-Hinds Lighting and controls 7000 lm 100-277 V

VMVL-7-J-R3-G-UNV1-S890

VMVL-7-J-R3-G-UNV1-S890 is an Eaton Crouse-Hinds Champ VMVL LED light fixture. It is a hazardous-location luminaire with a wire guard, glass lens, Type III optical distribution, and a Quick-Clip mounting system. This fixture is rated for 7000 lumens, 129 lm/W, 57 W, 100-277 Vac and 127-250 Vdc, with a frequency rating of 50/60 Hz. It has a NEMA 4X rating, IP66 ingress protection, cool white color temperature, and a 175W HID equivalent. Key Specifications

• Part Number: VMVL-7-J-R3-G-UNV1-S890
• Manufacturer: Eaton Crouse-Hinds
• Voltage: 100-277 V
• Frequency: 50/60 Hz
• Full Load Amps: 0.61-0.21 A
• Full Load Amp Min: 0.21 A
• Full Load Amp Max: 0.61 A
• Amperage Min: 0.21 A
• Amperage Max: 0.61 A
• Hz: 50/60 Hz
• Protection: IP66
• NEMA Rating: 4X
• Mounting: Stanchion 25° angled
• Configuration: Type III
• Special Features: Quick-Clip
• Temperature Rating: Cool white
• Lumens: 7000
• Lumens per Watt: 129 lm/W
• Wattage: 57 W
• Equivalent HID Luminaire: 175W HID
• Trade Size: 1-1/2 in
• Material: Die cast aluminum
• Lens Material: Heat and impact resistant glass

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: VMVL-7-J-R3-G-UNV1-S890
• Manufacturer : Eaton Crouse-Hinds
• Brand : Eaton Crouse-Hinds
• Category : Lighting and controls
• Item Subcategory : Highbay, lowbay and industrials
• Voltage : 100-277 V
• Full Load Amp Minimum : 0.21 A
• Full Load Amp Maximum : 0.61 A
• Configuration : Type III
• Full Load Amps : 0.61-0.21 A
• Nema Rating : 4X
• Amperage Maximum : 0.61 A
• Amperage Minimum : 0.21 A
• Watts : 57 W
• Metal Type : Die cast aluminum
• Mounting : Stanchion 25° angled
• Hz : 50/60 Hz
• Protection : IP66
• Dist Voltage : 100-277 Vac, 127-250 Vdc
• Material : Die cast aluminum
• NEC hazardous rating : Class I, Division 2 Class I, Zone 2 Class II, Division 1 Class III
• Ingress protection (IP) ratings : IP66
• Lumens : 7000
• Lumens per watt : 129 lm/W
• Color temperature : Cool white
• Mounting Method : Stanchion 25° angled
• Equivalent luminaire : 175W HID
• Guard type : Wire
• Power factor : > 0.90
• Trade size : 1-1/2"
• Special features : Quick-Clip
• IECEx/ATEX hazardous rating : Zone 21

Product Data

• UPC : 662276964372
• Dimensions : 15.07 in x 12.85 in x 11.62 in (Length/Depth x Height x Width)
• Weight : 22.5 lb
