2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Disconnect
Description
VH363NSSGL
VH363NSSGL is a Square D heavy duty fusible safety switch rated for 100 amps and 600 volts AC with 3 poles and surface mounting.This switch features a NEMA 1 enclosure, lug-type terminals, and is designed for heavy duty applications with a fusible disconnect. It supports 3-phase power and has a short circuit current rating of 10,000 A. The switch is constructed of steel and includes a handle actuator for easy operation.
- Manufacturer: Square D
- Part Number: VH363NSSGL
- Amperage: 100 A
- Voltage: 600 V AC
- Poles: 3
- Mounting Type: Surface
- Enclosure Type: NEMA 1
- Interrupt Rating: 10,000 A
- Terminal Type: Lug
- Material: Steel
- Phase: 3
- Type: Heavy Duty Fusible Disconnect
Specifications
- Part Number: VH363NSSGL
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Switch
- Item Subcategory : Disconnect
- Family : VH
- Voltage : 600
- Amperage : 100
- Phase : 3
- Poles : 3
- Wire : 3
- Configuration : Single
- Switch Style : Fusible
- Nema Rating : NEMA 4X
Product Data
- UPC : 060648589413
- GTIN : 03606485894133
- Country of Origin : United States
- Dimensions : 20.73 in (526.54 mm) x 9.336 in (237.134 mm) x 7.2 in (182.9 mm) (Height x Width x Depth)
- Weight : 23.92 lb
- Certification : UL listed file E2999
