VH361BAWKGL - Square D Heavy Duty Safety Switch 30A 600V 3 Pole NEMA 12 Viewing Window

VH361BAWKGL

This non-fusible safety switch features a 30 ampere rating, 600 volt AC/DC capacity, and a 3-pole configuration. It is housed in a Type 12 NEMA-rated enclosure made of galvannealed steel, providing protection suitable for indoor use against dust and dripping water. The switch includes a factory-installed viewing window for quick visual verification of the switch position and comes with factory-installed equipment ground lugs. It is surface mounted and supports wire ranges from AWG 12 to AWG 6 aluminum and AWG 14 to AWG 6 copper. The switch meets UL 98 and NEMA KS1 standards and is UL listed under files E2875 and E154828.

Key Specifications
• Amperage: 30A
• Voltage: 600V AC/DC
• Poles: 3
• Mounting Type: Surface Mount
• Enclosure Type: NEMA 12, Type 12
• Material: Galvannealed Steel
• Non-fusible
• Viewing Window: Factory Installed
• Equipment Ground Lugs: Included
• Wire Range: AWG 12-6 Aluminum, AWG 14-6 Copper
• Standards: UL 98, NEMA KS1
• UL Listed: Files E2875, E154828

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: VH361BAWKGL
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Switch
• Item Subcategory : Disconnect
• Family : VH
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• Fuse Class : J
• Wire : 3
• Configuration : Single
• Switch Style : Fusible
• Nema Rating : NEMA 12



Product Data

• UPC : 060648589383
• GTIN : 03606485893839
• Country of Origin : United States
• Dimensions : 14.57 in (370.08 mm) x 6.48 in (164.59 mm) x 5.195 in (131.953 mm) (Height x Width x Depth)
• Weight : 11.02 lb
• Certification : UL listed file E2957
