Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Disconnect
Description
VH324BGL
VH324BGL is a heavy duty fused safety switch by Square D designed for reliable power distribution with a viewing window and neutral bonded feature.This 3-pole safety switch is rated for 200 amps and 240 volts AC, with a high interrupt rating suitable for demanding applications. It features a Type 1 NEMA enclosure, ground lugs, and is compatible with both copper and aluminum wiring. The switch includes a fusible design for enhanced circuit protection and a viewing window for easy fuse inspection.
- Amperage: 200A
- Voltage: 240V AC / 250V DC
- Poles: 3
- Mounting Type: Surface mount, NEMA 1 enclosure
- Interrupt Rating: 200 kA
- Neutral Bonded
- Ground Lugs Included
- Fused Safety Switch
- Viewing Window for Fuse Inspection
- Compatible with Copper or Aluminum Wiring
- Series/Frame: VH Series
- Certifications: ARRA Compliant
Specifications
- Part Number: VH324BGL
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Switch
- Item Subcategory : Disconnect
- Family : VH
- Voltage : 240
- Amperage : 200
- Phase : 3
- Poles : 3
- Fuse Class : J
- Wire : 3
- Configuration : Single
- Switch Style : Fusible
- Nema Rating : NEMA 1
Product Data
- UPC : 060648589370
- GTIN : 03606485893709
- Country of Origin : United States
- Dimensions : 28.93 in (734.82 mm) x 16.61 in (421.89 mm) x 8.6 in (218.4 mm) (Height x Width x Depth)
- Weight : 54.5 lb
- Certification : UL listed file E2947
