USM2 - Eaton Midget Fuse Holder 800 VAC/1000 VDC 30 A 2 Pole DIN Rail

USM2

USM2 is a Midget fuse holder designed for reliable circuit protection in industrial and commercial applications. This fuse holder supports up to 30 A and is rated for 800 VAC/1000 VDC, making it suitable for a wide range of electrical systems. The 2-pole design features pressure plate connections and is mounted on a standard 35mm DIN rail for easy installation and space-saving panel layout. The holder is finger-safe (IP20) for added safety during fuse changes. The USM2 fuse holder is compatible with 1-1/2 in x 13/32 in (USM) midget fuses and is engineered for durability and ease of use. It features a robust polyamide housing and is designed for quick, tool-free fuse replacement. The unit is suitable for use in environments with temperatures ranging from -40 to 85 degrees Celsius.

• Amperage Rating: 30 A
• Voltage Rating: 800 VAC/1000 VDC
• Number of Poles: 2
• Mounting Type: DIN Rail
• Fuse Class: Midget
• Fuse Size: 1-1/2 in x 13/32 in (USM)
• Connection Type: Pressure Plate
• Material: Polyamide
• Temperature Rating: -40 to 85 deg C
• Standards: UL 4248-14, CSA C22.2, IEC 60269-2-1, RoHS Compliant
• Mounting Space: 3.07 in L x 1.38 in W x 2.32 in H
• Wire Range: 14 to 6 AWG

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: USM2
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Fuse
• Item Subcategory : Fuse Block
• Family : Ultrasafe
• Type : USM

Product Data

• UPC : 782001829988
• GTIN : 00782001829988
• Country of Origin : China
• Dimensions : 1.38 in x 3.07 in x 2.32 in
• Weight : 0.28 lb
• Certification : CSA Certified, UL Listed
