Product Info
- Manufacturer:Eaton
- Sub-Category:Environmental Seals/Fire Seals
Description
TWBS4036
TWBS4036 is an Eaton Crouse-Hinds series Thru-Wall Barrier TWB sealing block assembly designed to seal cables or conduits penetrating fire or non-fire rated walls. This elastomeric sealing block assembly features 3 openings and requires 4 frame spaces, accommodating cable outer diameters in the range of 1.750-2.000 inches. The device can seal from one to three cables depending on opening size range. Standard materials include a special elastomeric sealing material, cast malleable iron mounting frame and pressure plate, and steel clamping hardware. Key Specifications
- Part Number: TWBS4036
- Manufacturer: Eaton
- Product Type: Sealing block assembly
- Material: Elastomeric
- Number of openings: 3
- Frame spaces required: 4
- Opening size range: 1.750-2.000 inches
- Product dimensions: 13.5 in L x 7.88 in W x 4.5 in H
- Product weight: 15.6 lb
- Area classification: Ordinary/Non-Hazardous Locations
Specifications
- Part Number: TWBS4036
- Manufacturer : Eaton
- Brand : Eaton
- Category : Conduit & Fittings
- Item Subcategory : Environmental Seals/Fire Seals
- Section : Thru-Wall Barrier Cable and Conduit Sealing Device
- Type : For marine applications
- Diameter : 1.750-2.000 inches
- Nema Rating : Ordinary/Non-Hazardous Locations
- Shipping Dimensions : 13.5 in L x 7.88 in W x 4.5 in H
- Item QTY : 15.6 lb
- Material : Elastomeric
- Special features : 3 openings, 4 frame spaces required
Product Data
- UPC : 782274277271
- GTIN : 00782274000000
- Dimensions : 13.5 in x 4.5 in x 7.88 in (Length/Depth x Height x Width)
- Weight : 19.93 lb
