Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
TRS15/100R
TRS15/100R is a 0.15 Amp, 600 Volt AC/DC Class RK5 time-delay fuse designed for reliable circuit protection.This Eaton fuse features a dual element, current limiting design with a time delay to protect against transient surges. It is rated for 600 VAC and 600 VDC with an interrupting rating of 200,000 AIC at 600 VAC and 20,000 AIC at 600 VDC. The fuse has a cylindrical body measuring 13/16" x 5" and incorporates a rejection style design to prevent replacement errors. It is UL Class RK5 certified for low voltage applications.
- Key Specifications
- Amperage: 0.15 Amp
- Voltage Rating: 600 VAC / 600 VDC
- Fuse Class: RK5
- Time Delay: Yes (Dual Element)
- Interrupting Rating: 200,000 AIC @ 600 VAC, 20,000 AIC @ 600 VDC
- Physical Size: 13/16" x 5"
- Current Limiting: Yes
- Mounting Type: Cylindrical Cartridge
- Rejection Style Design: Prevents replacement errors
- Certifications: UL Listed Class RK5
Specifications
- Part Number: TRS15/100R
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Tri-Onic
- Type : TRS
- Voltage : 600
- Amperage : 15
- AIC rating : 200kA@600V
- Diameter : 0.56
- Class Rating : RK5
- Barrels : 1
Product Data
- UPC : 782001748517
- GTIN : 00782001748517
- Weight : 0.2
