TRM8/10 - Ferraz Shawmut Mersen 8/10A 250VAC Time Delay Midget Fuse 10kA Interrupt

TRM8/10

TRM8/10 is a Ferraz Shawmut Mersen time delay midget fuse rated for 8/10 amperes and 250 volts AC with a 10,000 amp interrupt rating.This Tri-Onic® TRM series fuse features a 12-second time delay at 200% rated load, providing reliable supplemental protection for small motors, transformers, and other high inrush current applications. It has a compact cylindrical body measuring approximately 1.5 inches by 13/32 inches, designed for easy mounting in midget fuse holders. Certified to UL 248-14 and CSA C22.2 standards, it ensures safety and performance in industrial and commercial electrical systems.

Key Specifications
• Amperage: 0.8 A (8/10 Amp)
• Voltage Rating: 250 VAC
• Interrupt Rating: 10,000 AIC (10 kA)
• Fuse Type: Time Delay Midget
• Series: Tri-Onic® TRM
• Dimensions: 1.5" length x 13/32" diameter
• Time Delay: 12 seconds at 200% rated current
• Certifications: UL 248-14, CSA C22.2
• Mounting: Standard midget fuse holders
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: TRM8/10
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Tri-Onic
• Type : TRM
• Voltage : 250
• Amperage : 8
• AIC rating : 10kA@250V
• Diameter : 0.41
• Class Rating : Midget
• Barrels : 1



Product Data

• UPC : 782001743154
• GTIN : 00782001743154
• Weight : 0.01
