TR4/10R - Eaton 0.4A 250V AC/DC RK5 Class Time-Delay Fuse

TR4/10R

TR4/10R is a 0.4 amp, 250 volt AC/DC time-delay fuse from Eaton's RK5 Class TR-R series designed for reliable circuit protection.This fuse features a dual element Tri-Onic® time delay design with a cylindrical polyester body, measuring 2 inches in length by 9/16 inch in diameter. It is rated for 250V AC and DC operation with an interrupting rating of 200,000 AIC at 250V AC and 20,000 AIC at 250V DC. The fuse is non-indicating and includes a rejection style design to prevent replacement errors. It meets UL and CSA standards and is RoHS compliant.

Key Specifications
• Amperage: 0.4 A
• Voltage Rating: 250 V AC / 250 V DC
• Fuse Class: RK5
• Speed: Time-Delay (Tri-Onic®)
• Interrupt Rating: 200 kA AC, 20 kA DC
• Poles: 1 (single barrel)
• Mounting Type: Fuse block style rejection
• Body Material: Polyester
• Dimensions: 2 in length x 9/16 in diameter
• Certifications: UL, CSA, RoHS compliant
• Visual Indication: Non-indicating
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: TR4/10R
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Tri-Onic
• Type : TR
• Voltage : 250
• Amperage : 4
• AIC rating : 200kA@250V
• Diameter : 0.56
• Class Rating : RK5
• Barrels : 1



Product Data

• UPC : 782001747541
• GTIN : 00782001747541
• Weight : 5.19
