TR2/10R - Eaton 2/10 Amp 250V AC/DC Time-Delay Fuse Class RK5 Dual Element

TR2/10R

TR2/10R is a 2/10 Amp, 250 Volt AC/DC time-delay fuse from Eaton's TR-R Class RK5 series designed for reliable circuit protection.This fuse features a dual element Tri-Onic® time delay design, providing current limiting and rejection style mounting to prevent replacement errors. It has a cylindrical polyester body measuring 9/16" diameter by 2" length, with an interrupt rating of 200,000 AIC at 600 VAC and 20,000 AIC at 250 VDC. The fuse is UL listed Class RK5 and suitable for both AC and DC applications.

Key Specifications
• Amperage: 2/10 Amp
• Voltage Rating: 250 V AC / 250 V DC
• Fuse Class: RK5
• Time Delay: Tri-Onic® Dual Element
• Interrupt Rating: 200,000 AIC @ 600 VAC, 20,000 AIC @ 250 VDC
• Body Material: Polyester
• Dimensions: 9/16" diameter x 2" length
• Mounting Type: Rejection style
• Certifications: UL Listed Class RK5
• Series: TR-R

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: TR2/10R
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Tri-Onic
• Type : TR
• Voltage : 250
• Amperage : 2
• AIC rating : 200kA@250V
• Diameter : 0.56
• Class Rating : RK5
• Barrels : 1

Product Data

• UPC : 782001747527
• GTIN : 00782001747527
• Weight : 0.08
