Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
TQC1110WL
TQC1110WL is a General Electric 10 amp, 240 volt, 1 pole molded case circuit breaker designed for reliable electrical protection.This circuit breaker features a THQC frame with a thermal magnetic trip unit, suitable for Q-Line panels. It has a 5 kA interrupting rating at 120 volts and supports cable-in cable-out lug-lug mounting for solid or stranded conductors from 14 to 10 AWG. The breaker provides instantaneous trip protection and is UL listed for safety compliance.
- Amperage: 10 A
- Voltage: 120/240 VAC
- Poles: 1
- Interrupt Rating: 5 kA @ 120 V
- Frame Type: THQC
- Trip Unit: Thermal Magnetic (Instantaneous Trip)
- Mounting Type: Cable-in Cable-out (Lug-Lug)
- Wire Range: 14-10 AWG solid or stranded
- Certifications: UL Listed
- Manufacturer: General Electric
Specifications
- Part Number: TQC1110WL
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Q-Line
- Type : TQC
- Voltage : 240
- Amperage : 10
- Phase : 1
- Poles : 1
- AIC rating : 5kA@120V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 78316402016
- GTIN : 40783164020166
- Weight : 0.4
