Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
TPS-1
TPS-1 is a 1A, 170VDC non-indicating, current-limiting fuse designed for DC power distribution and telecommunication applications. This TPS series fuse features a ferrule end design and is UL recognized for reliable overcurrent protection. The Eaton Bussmann TPS-1 fuse is constructed with a glass melamine tube and silver-plated brass ferrules for durability and consistent performance. It is current-limiting and non-indicating, making it ideal for use in DC circuits where high interrupting capacity is required. The fuse is designed for use with a compatible fuse holder and is suitable for telecommunication and power distribution panels.
- Part Number: TPS-1
- Manufacturer: Eaton
- Series: TPS
- Current Rating: 1A
- Voltage Rating: 170VDC
- Interrupting Rating: 100kA
- Mounting Type: Ferrule End (Requires Holder)
- Fuse Type: Cartridge
- Construction: Glass Melamine Tube, Silver-Plated Brass Ferrules
- Indication: Non-Indicating
- Application: DC Power Distribution, Telecommunication
- Certification: UL Recognized
Specifications
- Part Number: TPS-1
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Telpower
- Type : TPS
- Voltage : 170
- Amperage : 1
- AIC rating : 100kA@170VDC
- Connection : Ferrule
- Diameter : 0.56
- Barrels : 1
Product Data
- UPC : 051712196970
- GTIN : 00051712196970
- Dimensions : 0.56 in x 0.87 in x 0.56 in (Length/Depth x Height x Width)
- Weight : 0.2
